6x60W LED Moving Head Beam Wash Light

Send Inquiry
6x60W LED Moving Head Beam Wash Light
Details
Model：NST-0660
Brand：New Start
Country of origin：China
6x60W LED Moving Head Beam Wash Light is a multi-in-one stage lighting device that combines head, beam, color, and auxiliary lighting. Its functions can be detailed around "independent control of the lamp head + multi-effect composite output" : It is equipped with six independently driven light head units, each with a 60W RGBW four-color main light bead, and each group of light heads is paired with 21 RGB auxiliary light groups. The main light can switch between "sharp beam (narrow Angle focus)" and "soft color (wide Angle spread)" effects by focusing, and the auxiliary light can simultaneously output the ambient light layer. It achieves a dual visual hierarchy of "main light + auxiliary light";
Each lamp head supports independent vertical 270° head control, which can perform dynamic swaying in different directions on its own, or group linkage to form a smooth light trajectory. Combined with 0-100% linear dimming and 1-25Hz adjustable stroboscopic function, it can adapt to the rhythm timing of fast-paced performances or the soft transition of slow-atmosphere scenes.
In terms of control, it is compatible with DMX512 console, sound control (automatically switching effects to the rhythm of the music), auto-motion program (built-in preset light show), master-slave synchronization and other modes, which can meet the fine-tuning control requirements of professional lighting technicians and also enable one-click automatic scene adaptation for small parties.
Overall, the core of its functionality is to achieve a composite output of "beam + color + atmosphere + dynamics" with six independent light heads, covering the stage lighting requirements from compact Spaces (bars) to large venues (concerts).
Category
LED Effect Light
Share to

Guangdong New Start Lighting Co., Ltd. is one of the leading manufacturers and suppliers of 6x60w led moving head beam wash light in China. With abundant experience, we warmly welcome you to wholesale customized lighting products at competitive price from our factory. Contact us for pricelist.



Main Features

1. Light sources and effects

  • 6x60W RGBW 4-in-1 LED beads, combined with 6 sets of auxiliary lights (21x0.3W RGB beads), can achieve beam (narrow angle), color (wide angle), auxiliary light atmosphere triple effect;
  • Support 0-100% linear dimming, 1-25Hz stroboscopic (speed/random mode adjustable).

2 Dynamic control

  • The six heads support independent shaking/tilting (540° horizontally, 270° vertically) and can perform dynamic programs such as "independent swing" and "group linkage" to achieve a smooth light rhythm;
  • It supports focusing to switch between sharp beams and soft curtain effects.

3. Manipulation methods

  • Supports modes such as DMX512, voice control, auto, master-slave, and is compatible with professional lighting consoles or auto scenes.
  • Technical Specifications



Technical Specifications

  • Product Name: 6x60W LED Moving Head Beam Wash Light
  • Product Model: NST- 0660

Optical System

  • Light source: 6 60W 4-in-1 LED beads, auxiliary light: 6 groups of 21 0.3W RGB beads
  • White light color temperature: 6500K
  • Lifespan: 80,000 hours
  • Luminous flux: 66,000 lumens
  • Zoom Angle: 3.5°-36°
  • Coated lens maintains high brightness for a long time

Effect

  • Features: Single swing + dye + beam, focusing, auxiliary
  • Dimmer: 0-100% linear dimming system, 16-bit fine dimming
  • Y-axis scanning angle: 270°
  • Pixel by pixel, each LED controllable
  • Stroboscopic frequency: 1-30hz, no flicker
  • With RDM, Artnet
  • Magnetic encoders with automatic correction

Voltage And Power

  • Total power: 500W
  • Input voltage: AC90V-250V, 50-60HZ

Control System

  • Display: LCD display, screen can be inverted for display; 4 touch keys
  • Channels: 21CH/36CH /56CH
  • Control modes: master-slave, auto-run mode, DMX512 control mode, RDM control

Electrical And Interface

  • DMX Link: 3-pin DMX XLR
  • Power connection power input and output
  • Protection class: lP20 indoor use
  • Housing: Heat-resistant plastic module + hard metal, black/silver/white available

Light Specifications

  • Length: 950mm (37.40")
  • Width: 130 mm (5.11")
  • Height: 330 mm (12.99")
  • Net weight: 20 kg (44lbs)

Flight Case Specification

  • Length: 1100mm (43.7")
  • Width: 570 mm (22.44")
  • Height: 540 mm (21.25")
  • Net weight: 92kg (202.4lbs) (including 3 in 1 flight case)

Working Environment

  • Maximum ambient temperature: 40°C
  • Minimum operating temperature: -20°C
  • Maximum surface temperature: 65°C

Certification

  • ISO9001 Quality Management System certification
  • CE certification

Installation

  • Can be installed horizontally or vertically
  • Universal operating position
  • 2 fixed folding light hooks for 50mm light stands
  • Safety rope connection hole

Factory Configuration

  • Electronic Instruction Manual
  • Power cord, signal line
  • 2 fixed folding light hooks for 50mm light stands
