Outdoor Four Eyes LED COB Face Light

Send Inquiry
Outdoor Four Eyes LED COB Face Light
Details
Model：NST-200FS
Brand：New Start
Country of origin：China
Outdoor Four Eyes LED COB Face Light's primary feature is IP65 protection rating, means it can completely prevent dust from entering and withstand low-pressure water spray from all directions, ensuring stable operation in damp environments such as outdoors, during the rainy season, beside fountains, etc.
To meet professional requirements such as stage and photography, the lamp uses four 5COB beads (two warm white and two perfect white), and its key features include: high color rendering, color rendering index (Ra) usually around 90, which can truly reproduce the colors of objects. Supports color temperature adjustment between warm white (e.g. 3200K) and true white (e.g. 6500K), either continuously or in steps, to suit different scene atmospheres. For ease of integration into large lighting systems, the main control modes typically include the DMX512 control industry standard protocol, which can be precisely grouped and programmed via the console; Self-motion and voice-controlled modes, with built-in programs that can run automatically or change to the rhythm of the music, are suitable for use when there is no console. Master-slave synchronization, when multiple lights are connected in series, one can be set as the master and the rest will automatically synchronize its changes. In addition to the basic lighting and color temperature adjustment, it also supports linear dimming, brightness can be smoothly adjusted from 0% to 100%, and high-speed stroboscopic to create dynamic visual effects.
Category
Outdoor LED COB Face Light
Share to

Guangdong New Start Lighting Co., Ltd. is one of the leading manufacturers and suppliers of outdoor four eyes led cob face light in China. With abundant experience, we warmly welcome you to wholesale customized lighting products at competitive price from our factory. Contact us for pricelist.



Main Features

  • High-brightness light source: 4 COB beads (2 warm white, 2 perfect white)
  • Luminous flux: 11240 lumens (25°)
  • CTO color temperature adjustment: 3200K - 6500K
  • Small in size, light in weight, high in light efficiency, low in energy consumption
  • Smart light sensing can automatically turn on the light mode according to the environment and set the duration of the light
  • 0 to 100% smooth dimming function
  • Multiple speed stroboscopic effects
  • IP65 protection, suitable for outdoor use all year round

product-2730-988

Technical Specifications

  • Product Name: Outdoor Four Eyes LED COB Face Light
  • Product model: NST-200FS
  • Light source: 4 COB beads (2 warm white, 2 pure white)
  • LED lifespan: 80,000 hours

Optical System

  • Advanced optical systems
  • Light emission Angle: 25°
  • Color Index (CRI) : Ra≥92

Controls And Programs

  • 4 physical keys
  • Control Protocol: DMX512, RDM, primary and secondary
  • DMX channel modes: 3
  • Channel mode: /8/4/2 channel
  • Software Upgrade: Update the software via DMX connection

Electrical And Interfaces

  • Input voltage range: 110-240V to 50/60Hz
  • Power: 200W
  • Power socket: Waterproof Power Connector input/output
  • Signal input/output: Waterproof Signal (XLR)

Light Specifications

  • Length: 250mm (9.84")
  • Width: 240mm (9.84")
  • Height: 220mm (8.66")
  • Net weight: 5.4kg (11.88lbs)

Carton Specifications

  • Length: 550mm (21.65")
  • Width: 550mm (21.65")
  • Height: 390mm (15.35")
  • Weight: 25.7kg(56.54lbs) (including carton, 1 pack 4 standard)

Flight Case Specifications

  • Length: 1090mm (42.91.")
  • Width: 580mm (22.83")
  • Height: 620mm (24.4")
  • Weight: 75kg(165lbs) (including flight case, 1 pack 8 standard)

Working Environment

  • Maximum ambient temperature: 40°C
  • Minimum operating temperature: -20°C
  • Maximum surface temperature: 65°C
  • Protection level:IP65
  • Neutral salt spray test: 720 hours Data provided by the light source supplier

Certification

  • ISO9001 Quality Management System certification
  • CE certification

Installation

  • Can be installed horizontally or vertically
  • Universal operating position
  • 1 fixed eagle-claw lamp hook for 50mm lamp holder

Factory Configuration

  • Electronic Instruction Manual
  • Power cord
  • 1 fixed folding lamp hook for 50mm lamp holder
